COMMSCOPE CY1720-000 FiberGuide to Lightrax Adapter Kit User Guide
FiberGuide® to Lightrax Adapter Kit, 4 in x 4 in, yellow
- FiberGuide products are designed and manufactured to ensure total off-frame fiber cable protection
- FiberGuide maintains a minimum bend radius throughout the entire system, regardless the system size
- FiberGuide is an optical raceway system for central office, mobile switching center and data center applications
- Engineers and installers can benefit from the large suite of available FiberGuide design tools
Product Classification
Regional Availability Asia | Australia/New Zealand | EMEA | Latin America | North America
Portfolio CommScope®
Product Type Fiber raceway transitional section
Product Brand FiberGuide®
Product Series FGS
General Specifications
Product Feature Transition
Color Yellow
Orientation Horizontal
Section Type Transition Adapter
Dimensions
Height 101.6 mm | 4 in
Width 101.6 mm | 4 in
System Dimensions 102 mm x 102 mm (4 in x 4 in)
Material Specifications
Material Type Engineering Thermoplastic
Environmental Specifications
Flammability Rating CSA S143 | UL 2024 | UL 94 V-0
Halogen Characteristics Blue Angel | TCO ’99 | WEEE
Safety Standard CSA | UL
Packaging and Weights
Weight, net 0.51 kg | 1.124 lb
Regulatory Compliance/Certifications
Agency Classification
CHINA-ROHS Below maximum concentration value
REACH-SVHC Compliant as per SVHC revision on www.commscope.com/ProductCompliance
ROHS Compliant
