PRODUCT FEATURES:
– Specially designed for the Ford truck for an OEM look.
– 160 degree wide view angle for excellent visibility.
– Super CMOS technology provides a sharper picture day and night.
VEHICLE APPLICATIONS:
FORD
2004 – 2014 F-150
2008 – 2016 F-250 / F-350 / F-450
2009 – 2012 Flex
PARTS INCLUDED:
WIRING DIAGRAM:
*NOTE: The camera needs a +12V trigger. Power the camera at the headunit using RED Wire B or from the reverse light wire using RED Wire A. DO NOT connect both wires to +12V at the same time. Insulate the red wire that is not being used. Tap the Black wire to an existing ground lead, or ground Black wire securely to vehicle body metal.
INSTALLATION PROCEDURE:
